Baseband unit and RF unit functions are built-in BS6120/6120P F1821, which is based on the advanced SoC Base Station solution and carrier-grade hardware and software platform. BS6120 supports FDD LTE B1/B3 band and has two or four RF channels (2T2R or 4T4R). The Max. RF power per channel is 250mW. The UWB (Ultra Wide Band) positioning function is built in BS6120 to meet the customized requirement for underground mining coverage.

All-in-one design and high integration

Based on the advanced all-in-one SoC and Pico Base Station solution, baseband unit and RF unit functions are built-in BS6120. BS6120 has the characteristics of small size, high integration and high performance. On the carrier-grade software and hardware architecture BS6120 can run with 7*24 hours continuously, which conforms to the requirement of carrier-grade reliability.

High data throughput

BS6120 supports 2T2R or 4T4R MIMO smart antenna technology and flexible LTE carrier bandwidth defined by 3GPP organization, such as 5MHz, 10MHz, 15MHz and 20MHz. The Max. downlink data throughput can reach 400Mbps and the Max. uplink data throughput can reach 150Mbps on dual carrier mode.

LTE and UWB positioning dual mode

BS6120 supports LTE and UWB positioning dual mode. It is easy to be deployed in underground mines. The positioning accuracy of UWB reach less than 1 meter.

Energy saving and high environmental adaptability

BS6120 supports high efficiency natural cooling technology for green energy saving and can run with no noise. BS6120 supports flat, vertical, wall-mounted and other installation methods. It is easy to be installed and dismounted.
