Based on the advanced ARM and SoC 5G RAN platform, the 5G baseband and RF functions together are integrated inside MetaBTS BS5504. BS5504 is deeply customized for industry applications, such as underground mine, subway or tunnel construction and other 5G coverage scenarios. BS5504 can provide cost-effective, high-performance 5G radio access network solution for industrial 5G application.
Integrated design and high integration
Adopting integrated design, 5G baseband and RF functions are integrated internal BS5504 for lower power consumption and higher integration. BS5504 support N77/N78 band and 100MHz carrier bandwidth.
Large capacity and high data throughput
BS5504 supports 4T4R quad-channel with MIMO technology. The RF power is over 4*250mW and the peak data throughput can reach more than 1.5Gbps (Sub-6G). BS5504 supports uplink dominant subframe rationing to further enhance the uplink data throughput.
All-IP structure and flexible deployment
BS5504 is on all-IP architecture and 10Gbps backhaul interface to support flexible deployment. BS5504 has the characteristics of compact structure design, green energy saving, easy installation and maintenance. BS5504 supports flat, wall and pole mounting, etc.
